GAF Interactive Details
CAD Details ready made for your project!
Interactive Details are PDF files that allow the user to create and edit project specific construction drawings without any computer-aided design (CAD) software.
DRAWING MUST BE VIEWED IN ADOBE ACROBAT OR ADOBE READER TO ENABLE CUSTOM LAYERING

Step 1
Download the file

Step 2
Open file in acrobat

Step 3
Edit layers to customize assembly options.

Step 4
Select “Save as” to save uploaded file.
To learn more on how to use this tool watch the step by step video now.
